For the One-Person Band – The Roland BK-5 61 Key Backing Keyboard
With the debut of the RolandBK-5, Roland proudly sets another milestone in the history of auto-accompaniment instruments. The RolandBK-5 Backing Keyboard features high-quality, fresh sounds combined with an easy user interface and advanced features. It’s the perfect partner for the “one-man band” as well as music hobbyists and amateurs.
- Self-contained, do-everything keyboard with auto-accompaniment engine and built-in sound system
- Wide selection of sounds, Music Assistants, and Rhythms that cover a wide landscape of musical genres (including East-Europe, Latin-America, Asia, and more)
- Friendly graphical user interface
- Onboard effects, including reverb, chorus, EQ, multi-band compressor, and dozens of multi-effects
- Music rhythm compatibility with Roland BK-7m/E-series/G-series/VA-series instruments
- Compatible with backing formats (SMF, MP3, WAV, and Rhythm) directly from USB memory; instant audio recording onto USB memory
- Automatic chord detection for SMF files
- Video output to share SMF/MP3 Lyrics with friends or the audience on an external screen
SPECIFICATIONS
Keyboard
- 61 keys (velocity sensitive)
- Display: 160 x 160 dots Graphic LCD (with backlit)
Sound Generator
- Max. Polyphony: 128 voices (GM2/GS/XG Lite compatible)
- Sounds: 1,172 tones, 60 Drum Sets
- Multitimbral parts: 3 real-time parts (UP1, UP2, LWR) + 16 song parts
- Master Tuning: 415.3 to 466.2 Hz
- Key Control (Transpose): -6 to +5 in semitones (for audio/MIDI data)
- Tempo change: 20 to 250 BPM for SMF and rhythms, 75 to 125% for mp3 and WAV files
- Part mute functions: TRACK MUTE (Rhythms, SMF), CENTER CANCEL (mp3, WAV, AUDIO INPUT signals)
Real-time parts (UP1, UP2, LWR), Rhythms/SMF
- Reverb: 8 types (selectable via Makeup Tools)
- Chorus: 8 types (selectable via Makeup Tools)
- MFX: 84 types for real-time parts (selectable via Tone Part MFX)
- MFX: A and B for rhythm and SMF section (selectable via Makeup Tools)
- Parametric EQ: 6 presets + 1 User memory
- Multi-band compressor: 6 presets + 1 User memory
Rhythm
- Rhythms: 305 in 6 “Rhythm” families (localized rhythms for specific areas are included in the WORLD 1 and WORLD 2 families)
- Rhythm Composer: Internal Rhythm Composer, SMF-to-Rhythm Converter provided as PC application (Windows) on the bundled CD-ROM
- One Touch memories: 4 programmable registrations per rhythm
- Rhythm Makeup Tools: Instrument-oriented editing
Songs
- Real-time player: SMF (Format 0/1), KAR, mp3, WAV, mp3+CDG
- Song chord extractor: Automatic chord detection for SMF files
- SMF Makeup Tools: Instrument-oriented editing
Performance Memories
- Performance Lists: Unlimited number (storage on USB memory)
- Over 500 “Music Assistant” memories (internal memory)
- 5 “Factory Song” memories (internal memory)
- Performance memories per List: Max. 999
- Search function: Quick location of SMF, audio and JPG files on the connected USB memory
Demo
- Yes
Recording
- Media: USB Flash memory
- Song Save Format: Audio files: WAV (44.1 kHz, 16-bit linear)
Video
- Lyrics: SMF, mp3/WAV, mp3+CDG
- Slide shows: Picture folder linked to songs (recommended resolution: 512 x 384 or 1024 x 768 pixels)
Connectors
- PHONES jack x2: Stereo 1/4″ phone type
- AUDIO INPUT jack: Stereo miniature phone type
- AUDIO OUTPUT jacks (L/Mono, R/Mono): 1/4″ phone type
- USB COMPUTER connector (Type B, reception and transmission of MIDI data)
- USB MEMORY (Type A, data storage devices)
- MIDI connectors (IN, OUT): Visual Control function
- VIDEO OUTPUT jack: RCA-type (CVBS, PAL or NTSC selectable)
- Foot pedal jack: HOLD, SWITCH/EXPRESSION (programmable)
Other
- Panel Control Knobs: VOLUME
- Rotary encoder: Data dial
- Speakers: 10 cm x 2
- Rated power output: 12 W x 2
- Power supply: AC adaptor
- Power consumption: 1100mA
- Auto Off function: Off, 10 min, 30 min, 240 min
- Accessories: Owner’s Manual, AC adaptor, Power cord (for connecting the AC adaptor), Music rest, CD-ROM (Style Converter 4.0, USB driver)
Size and Weight (without Music Rest)
- Width: 1,044 mm (41-1/8) inches
- Depth: 317 mm (12-1/2 inches)
- Height: 129 mm (5-1/8 inches)
- Weight: 7.5 kg (16 lbs. 9 oz.)
Manufacturer: Roland
Model: BK-5
SKU: I274017-N-0-WHXA
UPC: 761294502037
